High Temperature Resistance Tape Series
Anti-Static PI/PET High-Temperature Tape
Anti-static PI/PET tape · PI/PET防静电高温胶带
Technical parameters
| Item | Specification |
|---|---|
| Base material | PET / PI |
| Thickness | 0.035 – 0.15 mm / customisable |
| Adhesive system | Silicone |
| Peel force | 4 – 8 N / 25 mm |
| Heat resistance | 200 – 250 °C |
Product characteristics
Outstanding high-temperature resistance and solvent resistance, no residual adhesive, an anti-static coefficient, and compliance with RoHS environmental and halogen-free standards.
Applications
Bonding insulation and anti-static protection under high-temperature working conditions in the electronics and electrical industry.
Masking and protecting metal surfaces during high-temperature spray painting and sandblast coating — peels off easily after baking without residual adhesive.
The tape uses anti-static-treated polyester film, treated on one or both sides, coated with imported silicone pressure-sensitive adhesive. Peel static voltage is below 50 V, ensuring components are not damaged.
High Temperature Resistance Tape Series
PI Gold Finger High-Temperature Tape
PI gold finger high temperature tape (Polyimide tape) · 聚酰亚胺胶带
- Base material
- PI
- Thickness
- 0.03 – 0.2 mm / customisable
- Adhesive system
- Silicone / Acrylic
PI Film (Polyimide Film)
PI Film (Polyimide Film) · 聚酰亚胺薄膜
- Base material
- PI
- Thickness
- 0.0125 – 0.15 mm
- Heat resistance
- 350 °C
PET (Polyester) High-Temperature Tape
PET (Polyester) High Temperature Resistant Tape · 聚酯高温胶带
- Thickness
- 0.05 – 0.15 mm (customisable)
- Width × Length
- Customisable
- Short-term heat resistance
- 200 °C
