High Temperature Resistance Tape Series
Red/White Composite Masking Tape
Red/White masking high temperature resistant tape · 红/白色复合美纹纸胶带
Technical parameters
| Item | Specification |
|---|---|
| Colour | Red / White |
| Base material | PET masking paper |
| Thickness | 0.2 mm |
| Peel force | 8 – 10 N / 25 mm |
| Heat resistance | 200 °C |
Product characteristics
Good high-temperature resistance, chemical-solvent resistance, high adhesive force, soft conformability, and no residual adhesive after removal.
Applications
Hardware spray painting, paint baking, PC boards, PCB circuit boards, circuit-board tin dip, wave-soldering capacitor braiding, coils, transformers, die-cut forming and high-temperature marking.
High Temperature Resistance Tape Series
PI Gold Finger High-Temperature Tape
PI gold finger high temperature tape (Polyimide tape) · 聚酰亚胺胶带
- Base material
- PI
- Thickness
- 0.03 – 0.2 mm / customisable
- Adhesive system
- Silicone / Acrylic
PI Film (Polyimide Film)
PI Film (Polyimide Film) · 聚酰亚胺薄膜
- Base material
- PI
- Thickness
- 0.0125 – 0.15 mm
- Heat resistance
- 350 °C
PET (Polyester) High-Temperature Tape
PET (Polyester) High Temperature Resistant Tape · 聚酯高温胶带
- Thickness
- 0.05 – 0.15 mm (customisable)
- Width × Length
- Customisable
- Short-term heat resistance
- 200 °C
